Needs BMS - Renogy Lifepo4 12v 50Ah Battery
This battery in particular was manufactured with a bad BMS. The cells are all balanced and we already opened the lid for you. There is easy access to the balance leads and main connectors. You can easily swap the BMS in here. Priced accordingly. We have 4s lifepo4 30a BMS units that will work well and are just $14.
This batch of batteries are all testing between 48-53ah. You can expect these work like new after you replace the BMS.
Take your deep cycle battery experience to the next level by investing into Renogy's LFP Battery, combining superior lithium-iron phosphate technology to provide a better solution to solar energy storage. Weighing at just a bit over 14.8 lbs, Renogy's LFP battery surpasses expectation by being lighter, compact, and more powerful than its lead-acid battery counterparts of 50Ah. Designed to replace conventional solar battery storage units such as sealed Sealed, AGM, or Gel batteries, utilize your LFP battery in power-sport applications, off-grid applications, solar energy storage, and more! Take a step into the right direction by pairing your solar system with one of the safest and highest-cycle battery chemistry yet.
Note:
- Please be aware that if the batteries' Battery Management System (BMS) is activated and the battery voltage shows 0V, you must use a compatible Li charger to reactivate our Li batteries.
- Make sure to tightly screw the battery terminals in, having loose battery terminals will cause the terminals to build up heat resulting in damage to the battery.
- DO NOT string this battery in series. It is made ONLY for parallel connections using identical batteries.
ELECTRIC CHARACTERISTICS | |
---|---|
Nominal Voltage: 12.8V | Energy Density: 114.4Wh/L |
Rated Capacity (0.2C): 50Ah | Internal Resistance: ≤50mΩ |
Minimal Rated Capacity (0.2C): 47.5Ah | Cycle Life (0.2C, 20±5°C): 80% DOD 2000 cycles |
Energy: 640Wh | Specific Energy: 95.5Wh/kg |
CHARGING PARAMETERS | DISCHARGE PARAMETERS |
---|---|
Charge Voltage: 14.4 ± 0.2V | Maximum Continuous Discharge Current: 50A |
Maximum Charge Current: 50A | Discharge Cut-off Voltage: ≥10V |
Charge Cut-off Voltage: 14.6V |
TEMPERATURE PARAMETERS OPERATION TEMPERATURE RANGE | TEMPERATURE PARAMETERS STORAGE TEMPERATURE RANGE |
---|---|
Charge:32~113°F/ 0~45°C | Less Than 1 Year:32~77°F/ 0~25°C |
Discharge:-4~140°F / -20~60°C | Less Than 3 Months:23~95°F / -5~35°C |
Recommended:73.4 ± 9°F / 23 ± 5°C |
MECHANICAL PROPERTIES | |
---|---|
Length: 197mm / 7.8 inch | Weight: 6.7 kg / 14.7 lbs. |
Width: 166mm / 6.5 inch | Housing Material: ABS+PC |
Height: 171mm / 6.7 inch | Terminal Model: M8x1.25x12mm |
Cell Model: IFR26650-3.4Ah | Assembly Method: 4S15P |
